Description

Smartvest Wireless Shock Detector for monitoring walls, large window fronts and objects which are not to be moved. The sensitivity of the detector can be set at three different levels, which means that it can be used flexibly and adapted to the environment. It can be installed without the need for wires or drilling thanks to its battery operation. The detector also transmits its functionality to the alarm panel several times a day meaning that you are informed in good time if the battery is low. The shock detector also has tamper protection via cover contact for reporting any manipulation.

Awards & Partners
Smart Security World
Smart Security World
https://c1.abus.com/asc-pim-assets-01/derivates/11/001/108/Partnersiegel_Smartvest__logos.jpg
https://c1.abus.com/asc-pim-assets-01/derivates/11/001/108/Partnersiegel_Smartvest__logos.jpg
Awards & Partners

Product advantages

  • Smartvest extension for monitoring walls, window fronts and objects which are not to be moved.
  • Sensitivity can be set at three different levels
  • Quick and cable-free installation without the need for wires or drilling thanks to battery operation
  • Tamper protection via cover contact
  • Automatic supervision with functional tests repeated daily and feedback sent to the Smartvest alarm control panel
  • Visual feedback via blue LED when starting up and in use
  • Low battery notification sent to the Smartvest alarm control panel

Downloads

General downloads:

Declarations of conformity:

Smartvest Wireless Shock Detector
Smartvest Wireless Shock Detector
Specifications
Area of application: Inside
Battery - battery operation: Yes
Battery - max. battery life: 1 y
Battery - quantity: 1
Battery - type: CR2032 (3V)
Colour: White
Compatible with Secvest: No
Compatible with Smartvest: Yes
Dimensions: (B x L x H) 27 x 14 x 68 mm
Display: LED
Gross weight: 0,056 kg
Housing material: Plastic
Max. humidity: 80 %
Max. operating temperature: 35 °C
Min. humidity: 10 %
Min. operating temperature: 0 °C
Net weight: 0,0018 kg
PSTI conformity required: No
Power consumption: 2,6 mA
Radio frequency: 868 MHz
Radio modulation: FSK
Sensor type: 3G Accelerometer
Standby power consumption: 0,014 mA
Tamper protection: Yes
Transmission power: 4,5 dBm
Wireless range: (Depending on installation) 30 - 100 m
