ABUS Wired Indoor Siren

Name: ABUS Wired Indoor Siren
Brand: ABUS August Bremicker Söhne KG

Description

AZSG10020

The inside siren is installed inside your building. It is the last and critical module of a complete alarm chain. The inside siren is an acoustic signal generator. You have a choice between two alarm modes in this case. Both signals are felt to be extremely loud due to the high acoustic pressure and the signal frequency. The remotely activated LED of the alarm siren can be used to detect the status of the alarm panel (armed/disarmed). The rugged plastic housing of the acoustic signal generator is protected against sabotage by a wall and cover contact. The inside siren is powered with 12 V.

For safe and proper operation, this equipment must be installed and regularly maintained by a professional trained by us. Arrange regular maintenance appointments with your installer to ensure continuous smooth operation with the latest security updates and new functions.

Product advantages

LED to display armed/disarmed status
Simple, inconspicuous design
Simple installation
90 dB(A) sound pressure @ 1m
Tamper detection for front and rear sides
Shock-resistant construction from polycarbonate

Downloads

General downloads:

Declarations of conformity:

CE Declaration of Comformity

Additional information:

Wiring Diagram

Specifications

Colour:	white
Compatible with:	Secoris, Secvest, Terxon
Current consumption:	100 mA
DC power supply:	12 V
Dimensions:	(WxHxD) 115x138x36 mm
Environmental class:	II
Gross weight:	0.212 kg
Height:	41 mm
Housing material:	POLYCARBONAT (PC)
Illuminant:	LED
Length:	145 mm
Max. Air humidity:	95 %
Max. Operating temperature:	40 °C
Mechanical protection:	No

Min. operating temperature:	-15 °C
Mounting location:	Indoors, Wall
Net weight:	0.174 kg
PSTI conformity needed:	No
Power:	1.2 W
Power consumption:	1.2 W
Product group:	Sirens and sounders
Sound pressure:	90 dB
Tamper monitoring:	Yes
VdS class:	without
WEEE group:	09
width:	119 mm
