Padlock Steel Rock 83/80

83/55

Robust and flexible: The Rock 83/55 padlock made of hardened steel and with interchangeable cylinder secures factory gates, warehouses and trucks. It can also be adapted to already existing bittings.

  • WARNING:  Cancer and Reproductive Harm - www.P65Warnings.ca.gov
All variants for Rock 83/55
Description
Both the lock body and the shackle of the Rock 83/55 resist attempts to break the padlock open with specially hardened steel. The possibility of a keyed-alike solution optimises key management.
As the cylinder can be exchanged, the padlock can be integrated into a keyed-alike bitting system. In other words, you only need one key to unlock several locks. One key can therefore be used to open the warehouse doors and unlock the tool cabinet if desired.
Thanks to its precision pin cylinder, locking and unlocking of the Rock 83/55 is particularly smooth. The double bolted locking mechanism inside increases security against manipulation attempts.
Depending on the place of use, it makes sense that the lock can only be locked with the key (key retaining). It's your choice: the Rock 83/55 is available in a variant with key retaining and in an automatic version, where pressing down the shackle is sufficient.

Technologies

  • Shackle and body made of hardened steel
  • Shackle made from hardened alloy steel
  • Double bolted
  • Can be adapted to meet various requirements within seconds - no special tools needed
  • 83/55: Patented ”Z-Bar“ for 2-in-1 function: converts key-retaining to non-key-retaining and vice versa within seconds
  • 83/60 and 83/80: Key-retaining: Lock retains key until locked
  • CS: shackle guard protects shackle from attack
  • Precision pin cylinder
  • HB100: shackle detachable, particularly suitable for use in ConHasp Granit™ 215
  • 60 mm: SSF Kl. 3/ CEN Kl. 4; 80 mm: SSF Kl.4/ CEN Kl. 5
  • Cylinder cover available upon request

Use and application

  • To secure valuables/goods of greater value or at a high risk of theft
  • To secure gratings, doors, gates, cupboards, tool boxes, cellar windows, sheds, switchboards, barriers, etc.
  • Flexible: can be adapted to different requirements in a short time thanks to its interchangeable cylinder
  • Can be combined keyed alike with various ABUS door cylinders

Variants

  • Sizes: 2 23⁄64 and 3 5⁄32""

Downloads

General downloads:

Specifications
Locking type: key
color: silver
Horizontal clearance b: 63/64 inch
Shackle diameter d: 7/16 inch
Height f: 4 1/64 inch
Keyed alike: No
Structure: Technical drawing
Technical drawing
Security card: No
Width a: 2 11/64 inch
Vertical clearance c: 1 29/64 inch
Depth e: 63/64 inch
Weight [lbs]: 1.36 lbs
Security Level Home Security: 9
