Padlock 24IB/50 B/EFSPP Key

Diskus® 24IB/50

The Diskus® padlock ABUS Diskus® 24IB provides you with all-round protection against theft and corrosion.

All variants for 24IB Diskus®
Colours for 24IB Diskus®
Description
The ABUS Diskus lock is a special type of padlock with special advantages.
The Diskus lock’s shape effectively prevents the most common methods of breaking through. This means that the small shackle opening called for in the design offers hardly any space on the shackle for attacks. Due to the predominant use of stainless steel, the Diskus lock is most especially used in cases where security and corrosion protection are required. The ABUS Diskus 24IB can be used to lock trucks, doors, gates, barns, basements, sheds, etc. Ideally, an ABUS Diskus hasp should be used so that the shackle of the lock cannot be attacked with tools to pry it open.
  • Made in Germany

Technologies

  • Lock body, inner parts and shackle made solely from stainless steel for extreme resistance to corrosion
  • Cylinder cover – maximum protection against dirt and water spray (60 mm and 70 mm only)
  • Nickel-plated cylinder for enhanced weather protection
  • Original Diskus® design: 360° protection
  • Diskus® Deep-Welding Technology – the best in break-in protection
  • Precision pin cylinder
  • Key retaining: locking only with the key (key cannot be removed while the lock remains open)
  • Made in Germany

Operation and use

  • For the protection of larger assets and objects with a high risk of theft
  • Ideal for severe weather conditions (e.g., in sea and port areas, for securing vehicles and boats in outdoor use)
  • For securing trucks, doors, gates, barns, cellars, cupboards, etc.

Tips

  • Also ideal in combination with ABUS Diskus® Hasp 140, so the lock shackle cannot be attacked with tools

Variants

  • Sizes: 50, 60, 70 mm

Downloads

General downloads:

Specifications
Locking type: key
colour: stainless steel
Width a: 51 mm
Vertical clearance c: 8 mm
Depth e: 25,5 mm
Weight [g]: 129 g
Security Level Home Security: 7
Design: Technical drawing
Technical drawing
Security card: No
color of facets: silver
Horizontal clearance b: 13 mm
Shackle diameter d: 6,5 mm
Height f: 50 mm
Keyed alike: No
