Padlock aluminum 83AL/45 S blue (without cylinder) Padlock aluminum 83AL/45 S blue (without cylinder) Padlock aluminum 83AL/45 S blue (without cylinder)

83AL S TITALIUM™

83 series padlocks feature an interchangeable cylinder. The 83AL S TITALIUM™ for Snowman cylinders enables keying alike with existing keys and impresses with its low weight and high security.

  • WARNING:  Cancer and Reproductive Harm - www.P65Warnings.ca.gov
All variants for 83AL S TITALIUM™
Description
The 83AL S TITALIUM™ padlock makes security easy and weatherproof. The lock body owes its low weight and high robustness to the special aluminium Titalium.
Whether doors, gates, cupboards in the garden shed or the storage locker on a boat, they can all be secured with the 83TI S TITALIUM™. The robust padlock not only resists thieves, a special coating protects shackle and lock body from corrosion. A weather protection cap shields the cylinder from the weather and salt water.
One key – several locks
The padlock is not only adaptable when it comes to the choice of location. The cylinder of the 83AL S can be exchanged and thus matched keyed alike to existing bittings. The shackle can also be quickly exchanged and adapted to the existing conditions.
The 83AL TITALIUM™ proves that security can be light and flexible.
Awards & Partners
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 2) – Stockholm, Sweden (SBSC)
SBSC Klasse 2
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 2) – Stockholm, Sweden (SBSC)

CEN: Logo of the European norm for padlocks EN-12321 (class 3)
DIN EN 12320 KL 3
CEN: Logo of the European norm for padlocks EN-12321 (class 3)

Awards & Partners

Technologies

  • TITALIUM™ lock body – the special aluminium ensures high security with low weight
  • Hardened special steel shackle with NANO PROTECT™ coating for very high corrosion protection
  • Double bolted locking mechanism increases the security of the lock
  • 2 variants: with automatic locking by simply pressing down the shackle or with key retaining, i.e. locking only with a key (key retaining is set up by inserting the Z-bar)
  • Rekeyable: the cylinder can be exchanged and thus also adapted to existing bittings
  • Cylinder protection cap against moisture and dust optionally available
  • Shackle can be exchanged within seconds
  • Version “S”: lock body accepts standard Scandinavian Snowman cylinders

Use and application

  • Protection of items with a higher value and with a high risk of theft
  • Suitable for use on grilles, doors, gates, cabinets, toolboxes, cellar windows, sheds, switchgear, barriers, among other things
  • Extremely flexible: can be adapted to different requirements in a short time – thanks to its interchangeable cylinder and the possibility to quickly change the shackle

Variants

  • Size: 45 mm
  • Colours: red, blue, yellow, green, silver, black

Downloads

General downloads:

Specifications
Locking type: key
Security card: No
Width a: 1 27/32 inch
Vertical clearance c: 63/64 inch
Depth e: 53/64 inch
Weight [lbs]: 0.31 lbs
Security Level Home Security: 8
Structure: Technical drawing
Technical drawing
type of cylinder: without cylinder
color: blue
Horizontal clearance b: 15/16 inch
Shackle diameter d: 5/16 inch
Height f: 3 11/32 inch
Keyed alike: No
