Padlock 83/60 O without cylinder

Rock 83/60 O

This robust padlock with interchangeable cylinder offers high protection for goods and machines in warehouses, on construction sites and in factories. The Rock 83/60 O accepts Scandinavian oval cylinders.

  • Security Level 10/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for Rock 83/60 O
Description
The Rock 83/60 O is used where high-value assets need to be secured against access and theft.
The padlock secures warehouses, factory gates and trucks. It is also used in agriculture and on cargo ships. It owes its high resistance to attempts to break it open to the material used in its design: the solid lock body and shackle are made of hardened special steel.
The lock can also optimise key management and access control: you can conveniently integrate it into an existing security system by having your trusted specialist dealer adapt it to existing bittings. This is because the Rock 83/60 O is designed in such a way that the lock body can accept standard Scandinavian oval cylinders.
For even more flexibility, you can also choose between two options: in addition to the standard shackle, the high shackle variant with a vertical shackle clearance of 60millimetres is also available. No matter which variant you decide on, you are choosing a high level of security. The Rock 83/60 O achieves security class 4 of 6 according to the European padlock standard EN12320.
Awards & Partners
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 3) – Stockholm, Sweden (SBSC)
SBSC Klasse 3
Test seal of the Svensk Brand- och Säkerhetscertifiering AB (class 3) – Stockholm, Sweden (SBSC)

CEN: Logo of the European norm for padlocks EN-12322 (class 4)
DIN EN 12320 KL 4
CEN: Logo of the European norm for padlocks EN-12322 (class 4)

Awards & Partners

Technologies

  • Lock body and shackle made of hardened special steel
  • Hardened special steel shackle with NANO PROTECT™ coating for very high corrosion protection
  • Double bolted locking mechanism increases the security of the lock
  • Key retaining: locking only with key (when open, the key cannot be removed)
  • Rekeyable: the cylinder can be exchanged and thus also adapted to existing bittings
  • Cylinder protection cap against moisture and dust optionally available
  • SSF014 Class 3 / EN12320 Class 4
  • Version “O”: lock body accepts commercially available oval cylinders

Operation and use

  • Protection of items of high value and with a very high risk of theft
  • Suitable, among other things, for securing industrial or company gates, warehouses, trailers, containers and garages
  • Flexible: can be adapted to different requirements in a short time thanks to its interchangeable cylinder

Downloads

General downloads:

Specifications
Locking type: key
Security card: No
Width a: 60 mm
Vertical clearance c: 38 mm
Depth e: 28 mm
Weight [g]: 603 g
Security Level Home Security: 10
Design: Technical drawing
Technical drawing
type of cylinder: without cylinder
colour: silver
Horizontal clearance b: 25 mm
Shackle diameter d: 11 mm
Height f: 105 mm
Keyed alike: No
