    Powerline Adapter

    Description

    Network plug and play.
    Using the Powerline Adapter, every conventional socket is transformed into a secure and fast network connection in the blink of an eye.

    Full flexibility.
    You can directly operate your network device via the integrated socket. Create your own network with up to 16 adapters and combine with our Powerline PoE Adapter ITAC10310. In this case, data transmission also works cross-phase, which entails a reduction in the data rate to 80–90Mbit/s.

    Without compromising on security.
    With just one button, you can configure 128bit AES encryption, which makes your data transmission secure.

    Product advantages

    • Data transmission via available power grid
    • Integrated gigabit RJ45 connection
    • Integrated socket for powering your network device
    • Fast transmission rates of up to 1000 Mbit/s according to G.hn (HomeGrid standard)
    • Supports up to 16 adapters in a network
    • Secure transmission thanks to 128 bit AES encryption

    Downloads

    General downloads:

    Additional information:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    AC voltage supply: 110-240 V
    Dimensions: (LxWxH) 38 x 55 x 123 mm mm
    Height: 123 mm
    Length: 38 mm
    Max. humidity: 95 %
    Max. operating temperature: 40 °C
    Min. operating temperature: 0 °C
    Net weight: 0,185 kg
    Network Standards: IEEE 802.3
    Network access: 1x 10/100/1000 Mbit/s Base-T auto-sense
    Network camera protocols: 802.1D, 802.1Q, IGMP, MLD
    PSTI conformity required: No
    Power consumption: 12.500 mA
    Width: 55 mm
