    Specifications
    Alarm generation: PIR Sensor alarm
    Colour: white
    Connectable devices: Eycasa main unit
    Current consumption: 650 mA
    DC power supply: 5 V
    Data rate video: 2
    Focal length: 3,6 mm
    Frame rate: 20
    Frequency Video: 2.4 GHz
    Height: 120 mm
    Horizontal viewing angle: 60 °
    IR beam angle: 90 °
    IR range (up to): 8 m
    IR swivel filter: Yes
    Image sensor: 1/4" CMOS
    Length: 68 mm
    Lens: 3,6
    Max. Operating temperature: 50 °C
    Max. Resolution @ frame rate: 640 x 480 pixels (VGA)
    Min. operating temperature: -10 °C
    Modulation Video: FHSS+GFSK
    Net weight: 0.734 kg
    Number of IR LEDs: 27
    PIR range: 5 m
    PIR viewing angle: 60 °
    PSTI conformity needed: No
    Protection class IP: 66
    Radio range: 30 (depending on site conditions) * m
    Sensitivity video: -82
    Transmission power video: 13.5
    Video compression: MPEG-4
    width: 120 mm
