Padlock brass 82/90
Key

82 Monobloc

A brass padlock with a hardened steel shackle for protection in hard-to-reach areas.

  • Security Level 7/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
  • WARNING:  Cancer and Reproductive Harm - www.P65Warnings.ca.gov
All variants for 82 Monobloc
Description
The Monoblock 82 is designed with a hardened steel shackle and pin to provide maximum resistance to bolt cutters.
This padlock is made of special hardened steel and features a narrow side with a steel pin to prevent sawing manipulation. Its unique design allows for intuitive locking without the need for a key - simply press the shackle.
Application example - 722 Monobloc

Technologies

  • Solid lock body made from brass
  • 15/32" hardened special steel shackle
  • Hardened steel pin protects the narrow side of the lock body against sawing
  • Automatic locking: Locking without key by pushing down the shackle
  • Precision pin tumbler
  • Inner components made from rust-free materials
  • Incl. two keys

Use and application

  • 82/63 + 82/70: To secure valuables/goods of medium value or at an average risk of theft
  • 82/90: To secure valuables/goods of greater value or at a high risk of theft
  • For special applications, e.g. automats as well as gates, doors, containers, lorries, etc.
  • Ideally used with ABUS hasps No. 125 and 130

Variants

  • Sizes: 2 31/64", 2 3/4", 3 35/64"

Downloads

General downloads:

Specifications
Locking type: key
color: brass
Horizontal clearance b: 1 3/8 inch
Shackle diameter d: 15/32 inch
Height f: 2 13/32 inch
Keyed alike: No
Structure: Technical drawing
Technical drawing
Security card: No
Width a: 3 35/64 inch
Vertical clearance c: 45/64 inch
Depth e: 57/64 inch
Weight [lbs]: 1.57 lbs
Security Level Home Security: 7
