Padlock brass 82/90 Key

82 Monobloc

Brass padlock with hardened special steel shackle for securing hard-to-reach areas

All variants for 82 Monobloc

The Monoblock 82 is particularly suitable for locking areas that are difficult to access, such as roller grilles, vending machines, etc.

The shackle is made of hardened special steel. A hardened steel pin on the narrow side of the lock body protects against manipulation with sawing tools. Due to the special design, the padlock is locked intuitively without a key by simply pressing the shackle.
Application example - 722 Monobloc


  • Solid lock body made from brass
  • 12 mm hardened special steel shackle
  • A hardened steel pin protects the narrow side of the lock body against sawing
  • Automatic locking: Locking without key by pushing down the shackle
  • Precision pin cylinder
  • Inner components made from rust-free materials
  • Incl. two keys

Operation and use

  • 82/63 + 82/70: To secure valuables/goods of medium value or at an average risk of theft
  • 82/90: To secure valuables/goods of greater value or at a high risk of theft
  • For special applications, e.g. automats as well as gates, doors, containers, lorries, etc.
  • Ideally used with ABUS hasps No. 125 and 130


  • Sizes: 63, 70, 90 mm


General downloads:


We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Locking type: key
colour: brass
Horizontal clearance b: 35 mm
Shackle diameter d: 12 mm
Height f: 61 mm
Keyed alike: No
Design: Technical drawing
Technical drawing
Security card: No
Width a: 90 mm
Vertical clearance c: 18 mm
Depth e: 22,5 mm
Weight: 712 g
Security Level Home Security: 7
