Padlock Diskus® 28

28 Diskus®

Trust the original: Our Diskus® 28 padlock has a proven track record of securing high-risk objects.

  • Security Level 7/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
  • WARNING:  Cancer and Reproductive Harm - www.P65Warnings.ca.gov
All variants for 28 Diskus®
Description
The Diskus® 28 padlock is a proven choice for securing high-value items or objects at a high risk of theft.
Its round shape with a narrow stirrup opening and hand-welded welding seam ensure robust security. The Diskus® 28 padlock is suitable for protecting your valuables stored in barns, cupboards, cellars, or behind doors and gates. Crafted from stainless steel inside and out, with a shackle made of specially hardened steel, it offers exceptional tamper resistance. Its hand-welded seam ensures a strong and secure construction. For added protection, consider pairing the Diskus® 28 with our matching hasp 140.
  • Made in Germany

Technologies

  • Original Diskus® design: 360° protection
  • Diskus® Deep-Welding Technology - maximum strength
  • Hardened steel shackle
  • Precision pin tumbler cylinder with anti-pick pins
  • Key retaining: locking only with the key (lock retains key until locked)
  • Made in Germany

Use and application

  • To secure valuables / goods of greater value or at a high risk of theft
  • To secure doors, gates, cupboards, cellar doors etc.
  • Ideally used with ABUS Diskus® Hasp 140: virtually impossible to attack shackle

Variants

  • Sizes: 60, 70 mm

Downloads

General downloads:

Application example - Diskus® 28
Application example - Diskus® 28
Specifications
Locking type: key
color: stainless steel
Horizontal clearance b: 49/64 inch
Shackle diameter d: 25/64 inch
Height f: 2 3/4 inch
Keyed alike: No
Structure: Technical drawing
Technical drawing
Security card: No
Width a: 2 3/4 inch
Vertical clearance c: 11/16 inch
Depth e: 1 1/16 inch
Weight [lbs]: 0.58 lbs
Security Level Home Security: 7
