Padlock 20/70 ka. as per sample/code Code Card Plus with key

20 Diskus®

It depends on the form: With this DISKUS® padlock with all-round protection, ABUS Plus cylinder and cylinder cover, you protect your valuables not only against theft, but also against dirt and splash water.

All variants for 20 Diskus®
Colours for 20 Diskus®

Our padlock Diskus® 20 has proven itself to secure very high value assets or objects with a very high risk of theft.

The round shape with narrow stirrup opening and the welding seam ensure solid safety! The Diskus® 20 padlock protects your valuables that you store in trucks, vans or behind factory gates, for example. The lock is made of stainless steel on the inside and outside, the shackle is made of special hardened steel, which makes it particularly tamper-proof. The seam that holds the two stainless steel shells together is also hand-welded on the Diskus® 20, which leaves our production facility in Germany. This means that the two halves cannot be easily broken apart and the Diskus® secures your valuables and objects very well. Tip: Combine the Diskus® 20 with the matching hasp 140.
  • Made in Germany
Awards & Partners
Test seal of SKG with one star –The Netherlands
Test seal of SKG with one star –The Netherlands

Awards & Partners


  • Stainless steel - outside and inside
  • Additional protection against sawing
  • Shackle made from high quality stainless steel
  • ABUS-Plus disc cylinder: highest protection against manipulation, extremely high number of key differs
  • Cylinder cover – maximum protection against dirt and water spray
  • Sophisticated Diskus® welded seam for highest break resistance
  • Original Diskus® design: 360° protection
  • Key retaining: key is needed for locking (lock retains key until locked)
  • SZP: comes with security card to protect against unauthorized key duplicates
  • Made in Germany
  • 2 keys

Operation and use

  • To secure valuables/goods of great value or at a very high risk of theft
  • To secure e.g. warehouses, industrial sites, factory gates, containers and lorries
  • Ideally used with ABUS Diskus® Hasp 140: virtually impossible to attack shackle


  • This traditional lock comes in a wide range of sizes


  • Sizes: 70, 80 mm


General downloads:


We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
The disc lock is a special form of the padlock with some distinct advantages.
Locking type: key
colour: stainless steel
Width a: 70 mm
Vertical clearance c: 17 mm
Depth e: 30,5 mm
Weight: 306 g
Security Level Home Security: 9
Design: Technical drawing
Technical drawing
Security card: No
color of facets: silver
Horizontal clearance b: 20 mm
Shackle diameter d: 10 mm
Height f: 70 mm
Keyed alike: No
