    Digital access control for companies: efficient and convenient, online-capable and radio-networked. Software management and app for 160 doors. The wAppLoxx Pro Plus electronic locking system.

    Description

    DIGITAL, RADIO-NETWORKED LOCKING TECHNOLOGY FOR 160 DOORS

    The electronic locking system for real-time access management in commercial properties and public facilities. The Control unit manages the radio networked wAppLoxx Pro Plus system including all door cylinders, other components, and the app. The integrated software is included free of charge. It can be operated online (remote access) or via LAN, data transmission is always encrypted and made via a secure connection.
    Extensive, flexible, well organized
    One control integrates up to 32 door components and 6 radio repeaters into one system. Need more? Just combine up to 5 control units and scale up to 160 doors (1:4 cascading). The software's transparent locking plan matrix manages 1,000 users in 160 door groups and 100 user groups.
    Efficient software management and app operation
    Complex building access requirements are conveniently set up in the intuitive software. Locking rights and operations are controlled, changed, and monitored directly here - all changes are applied at the push of a button (high-performance real-time management). The system is designed for the integration of 2 alarm systems (EMA) for de-/activation directly at the door and for 10 IP cameras for access verification via video image. Popular feature: The app turns any smartphone into a locking medium.
    This makes wAppLoxx Pro Plus the perfect locking system for companies and the public sector.

    Product advantages

    • Central control unit for the wAppLoxx Pro Plus system operated via radio network
    • Integrated software for programming and managing the locking system by up to 1,000 users (wAppLoxx Pro Plus Manager)
    • Possible operating modes: offline, local network, and online with internet connection
    • Up to 32 wireless door components can be integrated per WLX Pro Control Plus, with a maximum of 6 WLX Pro Repeaters each
    • Up to 5 control units can be combined to scale the system up to a total of 160 WLX Pro door components
    • Locking permissions are assigned in the locking plan matrix for up to 160 door groups and 100 user groups
    • Flexible access release - even while on the road - for all wAppLoxx Pro door components via iOS/Android app (with costs)
    • Control of up to 2 intrusion alarm systems or 2 security areas directly at the door (forced protection against false alarms) as well as integration of up to 10 ABUS IP cameras for access verification (live image in the app)
    • Intelligent event control (e.g. e-mail sent in the event of an invalid access attempt)
    • Automatic provision of software updates

    Downloads

    General downloads:

    Declarations of conformity:

    Additional information:

    Software:
    Firmware:

    Installation software:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    WLX Pro Control Plus
    WLX Pro Control Plus
    Specifications
    Article abbreviation: WLX-PP-CTRL
    Closing media: 1000
    Colour: white
    Compatible with: WLX Pro
    Connections: Relay 1-4: 30 V DC / 2A max. - Inputs 1-6: 0V/12V / 0.1A max.
    Current consumption: 500 mA
    DC power supply: 1,5 A / 12 V
    Depth: 53 mm
    Dimensions: 277 × 247 × 53 mm
    Encryption: AES 128-bit
    Environmental conditions: max. 80% relative humidity, non-condensing
    Height: 247 mm
    Housing material: Plastic
    Length: 53 mm
    Max. Operating temperature: 40 °C
    Min. operating temperature: 0 °C
    Mounting type: Surface mounted
    Net weight: 0.996 kg
    PSTI conformity given: Yes
    PSTI conformity needed: Yes
    Product security update min until: 2030-12-31
    Protocol and time function: Yes
    Radio frequency: 868.3 MHz
    Radio functions: Permissions can be selected for access and/or arm/disarm, special keys for security services, remote access authorisation, remote arm/disarm, event control and email notification, log and time function, camera integration
    Radio range: up to 30 m indoors / free field nominal 100 m
    VdS class: ohne
    signaling: Status LEDs
    width: 277 mm
