    Padlock 20/70
    Code Card Plus with key

    20 Diskus®

    It depends on the form: With this DISKUS® padlock with all-round protection, ABUS Plus cylinder and cylinder cover, you protect your valuables not only against theft, but also against dirt and splash water.

    • Security Level 9/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for 20 Diskus®
    Colours for 20 Diskus®
    Description
    Our padlock Diskus® 20 has proven itself to secure very high value assets or objects with a very high risk of theft.
    The round shape with narrow stirrup opening and the welding seam ensure solid safety! The Diskus® 20 padlock protects your valuables that you store in trucks, vans or behind factory gates, for example. The lock is made of stainless steel on the inside and outside, the shackle is made of special hardened steel, which makes it particularly tamper-proof. The seam that holds the two stainless steel shells together is also hand-welded on the Diskus® 20, which leaves our production facility in Germany. This means that the two halves cannot be easily broken apart and the Diskus® secures your valuables and objects very well. Tip: Combine the Diskus® 20 with the matching hasp 140.
    • Made in Germany
    Awards & Partners
    Test seal of SKG with one star –The Netherlands
    SKG*
    Test seal of SKG with one star –The Netherlands

    Awards & Partners

    Technologies

    • Stainless steel - outside and inside
    • Additional protection against sawing
    • Shackle made from high quality stainless steel
    • ABUS-Plus disc cylinder: highest protection against manipulation, extremely high number of key differs
    • Cylinder cover – maximum protection against dirt and water spray
    • Sophisticated Diskus® welded seam for highest break resistance
    • Original Diskus® design: 360° protection
    • Key retaining: key is needed for locking (lock retains key until locked)
    • SZP: comes with security card to protect against unauthorized key duplicates
    • Made in Germany
    • 2 keys

    Operation and use

    • To secure valuables/goods of great value or at a very high risk of theft
    • To secure e.g. warehouses, industrial sites, factory gates, containers and lorries
    • Ideally used with ABUS Diskus® Hasp 140: virtually impossible to attack shackle

    Tips

    • This traditional lock comes in a wide range of sizes

    Variants

    • Sizes: 70, 80 mm

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    To view this content, you must agree to the use of cookies.

    The disc lock is a special form of the padlock with some distinct advantages.
    Application example - Diskus® 20
    Application example - Diskus® 20
    Specifications
    Locking type: key
    colour: stainless steel
    Width a: 70 mm
    Vertical clearance c: 17 mm
    Depth e: 30,5 mm
    Weight: 306 g
    Security Level Home Security: 9
    Design: Technical drawing
    Technical drawing
    Security card: No
    color of facets: silver
    Horizontal clearance b: 20 mm
    Shackle diameter d: 10 mm
    Height f: 70 mm
    Keyed alike: No
