Padlock 86 TITALIUM™

86 TITALIUM™

Keyed alike: Our 86 Titalium™ can easily be integrated into existing locking systems.

  • Security Level 7/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
  • WARNING:  Cancer and Reproductive Harm - www.P65Warnings.ca.gov
All variants for 86 TITALIUM™
Description
Our 86 Titalium™ can easily be integrated into existing locking systems.
Systematically secure your control cabinets, doors, gates, lockers, or sheds against break-in attempts with this robust padlock. The solid lock body is made of TITALIUM™ special aluminum, the hardened steel shackle is equipped with NANO PROTECT™ coating. The lock comes without a lock cylinder. Commercially available Euro profile half cylinders can be installed in the padlock using a conventional Allen key so that it can be integrated into existing locking systems.
Application example - 86 TITALIUM™

Technologies

  • Solid lock body made from TITALIUM™ aluminum alloy - high security with low weight
  • Hardened steel shackle with NANO PROTECT™ plating for extreme corrosion resistance
  • Customary EURO-cylinders can be integrated easily without special tools
  • Double bolted shackle
  • Possible to integrate into keying systems
  • 86TI/55: Key retaining or automatic locking (depending on position of cam)
  • 25°: Automatic locking (only for adjustable strike plates)
  • 45°: Key-retaining
  • 86TI/45: Key retaining

Use and application

  • To secure valuables/ goods of greater value or at a high risk of theft
  • To secure doors, gates, cupboards, tool boxes, cellar windows, sheds, switchboards, etc.

Variants

  • Sizes: 1 49/64" and 2 11/64"
  • IB: with stainless steel shackle (45mm only)

Downloads

General downloads:

Specifications
Locking type: key
Security card: No
Width a: 1 53/64 inch
Vertical clearance c: 1 9/32 inch
Depth e: 1 1/16 inch
Weight [lbs]: 0.41 lbs
Security Level Home Security: 7
Structure: Technical drawing
Technical drawing
type of cylinder: without cylinder
color: aluminum
Horizontal clearance b: 1 3/64 inch
Shackle diameter d: 5/16 inch
Height f: 3 51/64 inch
Keyed alike: Yes
