86 TITALIUM™

Keyed alike: Our 86 Titalium™ can be easily integrated into existing locking systems.

All variants for 86 TITALIUM™
Description
Our 86 Titalium™ can be easily integrated into existing locking systems.
Secure your switch cabinets, doors, gates, lockers or sheds consistently against break-in attempts with this robust padlock. The solid lock body is made of TITALIUM™ special aluminium, the hardened steel shackle is equipped with NANO PROTECT™ coating. The lock is supplied without a lock cylinder. Commercially available Europrofile door half cylinders can be installed in the padlock with a conventional hexagon socket wrench in order to integrate it into already existing locking systems.

Technologies

  • Solid lock body made from TITALIUM™ aluminium alloy - high security with low weight
  • Hardened steel shackle with NANO PROTECT™ plating for extreme corrosion resistance
  • Customary EURO-cylinders can be integrated easily without special tools
  • Double bolted shackle
  • Possible to integrate into keying systems
  • 86TI/55: Key retaining or automatic locking (depending on position of cam)
  • 25°: Automatic locking (only for adjustable strike plates)
  • 45°: Key-retaining
  • 86TI/45: Key retaining

Operation and use

  • To secure valuables/ goods of greater value or at a high risk of theft
  • To secure doors, gates, cupboards, tool boxes, cellar windows, sheds, switchboards, etc.

Variants

  • Sizes: 45 and 55 mm
  • IB: with stainless steel shackle (45mm only)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
Locking type: key
Security card: No
Width a: 46,5 mm
Vertical clearance c: 32,5 mm
Depth e: 27 mm
Weight: 185 g
Security Level Home Security: 7
type of cylinder: without cylinder
colour: aluminum
Horizontal clearance b: 26,5 mm
Shackle diameter d: 8 mm
Height f: 96,5 mm
Keyed alike: Yes
