Hasp 141/200 white

141 Diskus® Integral

For vans, panel vans and storage containers: Our DI141 Diskus® Integral has a universally applicable hasp with an integrated Diskus® lock.

All variants for 141 Diskus® Integral
Description
Our DI141 DISKUS® Integral hasp has a security hasp with integrated Diskus® lock and fits the most common transportation and storage containers.
Versatile, double protection: With our Diskus® integral hasps you secure doors and gates without a rebate. Our Diskus® integral hasps were especially developed to secure motor vehicle wing and sliding doors. However, they are an equally very good way to protect barns and containers from break-ins. The integrated Diskus® lock of 70 millimetres is protected by a robust metal lock casing all around from breaking open and from splash water. The frontal cylinder access enables convenient operation.
  • Made in Germany

Technologies

  • Universal hasp with integrated Diskus® padlock (70 mm) for doors and gates without rebate
  • Easy to operate with one hand due to handy frontal cylinder access
  • Extremely corrosion resistant cylinder
  • Solid metal locking case almost completely prevents successful attacks on the integrated padlock
  • Interchangeable Diskus® lock
  • Fixing material (screws, drilling template and spacers up to 5 mm height levelling) and Diskus® lock are included
  • Corrosion protected

Operation and use

  • Universal hasp with integrated Diskus® padlock to secure doors and gates without rebate
  • Will fit on most common transport and storage containers
  • Also ideal for use on double wing doors (transporters, box waggons)
  • Only for 70-mm Diskus padlock

Variants

  • Colours: white, black
  • Supplied with or without optional Diskus lock
  • Includes mounting and height-adjustment materials (up to 5 mm) and drilling template

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
colour: white
Width b: 87,3 mm
Weight: 1270 g
Design: Technical drawing
Technical drawing
Length a: 222 mm
Eyelet bore hole c: 13,4 mm
Security Level Home Security: 10
