    SFP Module Singlemode
    SFP Module Singlemode
    SFP Module Singlemode

    SFP Module Singlemode

    Description

    For promising networking of professional security surveillance systems.
    The standardised SFP module is used to connect duplex single-mode optical fibres.

    It is compatible with all standardised SFP slots and is required for use of the LWL port in our switches and the media converter.

    Product advantages

    • SFP modules for LC plugs according to SFF-8472 standard
    • Supports hot-plug
    • Supports single-mode optical fibres
    • Transmission distance of up to 20 km
    • 1310 nm FP laser
    • Complies with the IEC-60825 laser safety standard

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    SFP Module Singlemode
    SFP Module Singlemode
    Specifications
    DC voltage supply: 3.15V～3.45V V
    Dimensions: (LxWxH) 56 x 14 x 6 mm mm
    Height: 6 mm
    Length: 56 mm
    Max. humidity: 95 %
    Max. operating temperature: 70 °C
    Min. operating temperature: 0 °C
    Net weight: 0,017 kg
    Optical Fibre Port: LC
    Optical Fibre Type: Single mode 9/125um
    Optical Wave Length: 1.310 nm
    PSTI conformity required: No
    Power consumption: 1 W
    Transmission distance: 20.000 m
    Width: 14 mm
