Combination lock 158/50 B/DFNLI

158

The good combination: Robust padlock with robust zinc die-cast body, number code and double locking to protect your valuables against theft.

All variants for 158
Colours for 158
Description

Our combination lock 158 with double shackle locking mechanism and has an individually resettable number code.

To secure valuables at average risk of theft, our combination lock 158 is a good solution. The lock body consists of a zinc die-cast body, the shackle of hardened steel. The lock is available in three-digit, four-digit and five-digit code variants. The bracket closes with a double lock. We recommend using hasps 100, 110 and 300 for this padlock.

Technologies

  • Solid zinc-die cast body
  • Shackle made from hardened steel
  • Double bolted shackle
  • 158/40: individually resettable 3-digit code
  • 158/50: individually resettable 4-digit code
  • 158/65: individually resettable 5-digit code
  • CS: Shackle guard protects shackle from attack

Operation and use

  • To secure valuables/goods of medium value or at an average risk of theft
  • Suitable to secure doors, gates, cupboards, lockers, tool boxes, cellar windows, sheds, switchboards, etc.
  • Ideally used with ABUS Hasps No. 100, 110, 300

Variants

  • Sizes: 40, 50, 65 mm
  • High shackle (HB): 158/50HB50 & 158/50HB63
  • Closed shackle (CS): 158CS/50 and 158CS/65

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging
Specifications
Locking type: number combination
colour: anthracite
Width a: 52 mm
Vertical clearance c: 33 mm
Depth e: 23 mm
Weight: 256 g
Security Level Home Security: 5
Design: Technical drawing
Technical drawing
Security card: No
color of facets: grey
Horizontal clearance b: 26 mm
Shackle diameter d: 8 mm
Height f: 96 mm
Keyed alike: No
