    ABUS Analogue HD/6-Channel Hybrid Video Recorder
    Video Recorder
    Video Recorder

    ABUS Analogue HD Video Surveillance 8-Channel Hybrid Recorder

    Product advantages

    Downloads

    General downloads:

    Declarations of conformity:

    Additional information:

    Software:
    Firmware:

    Installation software:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    Alarm generation: Acoustic warning signal, OSD signal, e-mail
    Article program: Performance
    Audio input: 1x RCA (2.0Vp-p, 1kΩ)
    Audio output: 1x RCA (Linear, 1kΩ)
    Battery - quantity: 1
    Compatible with Secvest: No
    Compatible with Smartvest: No
    Compatible with wAppLoxx: No
    DC power supply: 12 V
    Decoding performance (local live view & playback): 4x 2MPx
    Dimensions: (W x L x H) 315 x 240 x 48 mm
    Gross weight: 2.899 kg
    Housing: 1U Chassis
    Housing material: Metal, Plastic
    Language OSD: DE, UK, FR, NL, DK, IT, PL, ES, SE
    Max. Air humidity: 90 %
    Max. Operating temperature: 55 °C
    Max. Resolution @ frame rate: TVI: 8 MPx, 5MPx, 4MPx, 3MPx, 2MPx @ 30fps / 1MPx @ 60 fps AHD: 5MPx, 4MPx, 2MPx, 1MPx @ 30fps CVI: 4MPx, 2MPx, 1MPx @ 30fps CVBS: Support
    Min. humidity: 10
    Min. operating temperature: -10 °C
    Net weight: 2.072 kg
    Network connection: 1x RJ-45 10/100 Mbit/s self-adaptive Ethernet interface
    Network protocols: TCP/IP, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
    PSTI conformity needed: No
    Power: 21 W
    Power consumption excl. hard disk: 15
    Product group: Video
    Recording modes: Manual, time schedule, motion detection, alarm
    Resolution HDMI output: 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz
    Resolution VGA output: 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz
    Resolution recording @ frame rate per camera: 8MPx @ 8 fps / 5MPx @ 12fps / 4MPx @ 15 fps / 3 MPx @ 18 fps / 2MPx, 1MPx, WD1, 4CIF, VGA, CIF @ 30 fps
    Software: ABUS Link Station (iOS & Android) / IP Installer
    Storage medium: 1x Sata interface (3,5" HDD, max. 6TB) / NAS
    Supported IP cameras: TVIP1156x, TVIP21560, TVIP41500, TVIP4x56x, TVIP41660, TVIP615x0, TVIP6x56x, TVIP82900
    Supported browsers: IE11 (Plugin)
    Synchronized playback: 4
    Total network throughput (input/output): 72 Mbit/s
    Total video channels: 8
    USB connection: 2x USB 2.0
    Video channels HD-TVI: 4
    Video channels IP: 8
    Video compression: H.264 / H.264 Plus / H.265 / H.265 Plus / H.265 Plus Pro
    Video input: 4x BNC (1.0Vp-p, 75Ω)
    WEEE group: 09
