    Network Mini Dome Camera
    Network Mini Dome Camera

    ABUS IP video surveillance 2MPx Wi-Fi mini dome camera

    Description

    Monitoring in any wind and weather conditions
    With a high, detailed Full HD resolution of 1920 x 1080 pixels and a wide 115° viewing angle, the TVIP42561 2Mpx WLAN Mini Dome Camera records 25 images per second. This makes it a versatile surveillance solution, e.g. at home or in the office. Due to the robust and weatherproof housing with protection class IP67, the camera is very well suited for indoor as well as outdoor use.

    Flexible location: in entrance areas, in the garden, ...
    Thanks to WDR with 120dB, the camera can be used universally, even under strongly fluctuating and difficult conditions with a lot of backlight, e.g. in the entrance area or in the garden. The integrated microSD card slot serves for recording directly in the camera and for playback via browser or app. Thanks to H.265 Plus for strong compression of the video data, the camera records 6x longer than H.264. Motion detection ensures lower memory requirements in advance. The camera also has integrated infrared LEDs for a view of up to 30 meters in darkness/night (depending on the location). There is no annoying cable clutter during installation. Two options make this possible: power supply via the network cable (PoE) or operation via WLAN so that only the power cable leads to the socket.

    Access to live images & recordings: secure and easy
    The camera simply connects directly to the ABUS Link Station app on the smartphone or tablet via an encrypted end-to-end connection (E2E) - and without any settings on the router. With the Lite version of the app, up to 60 minutes of data stream (live view/playback) per month via Internet or Wi-Fi are completely free. Or with the ABUS Link Station Pro: Buy once and access unlimited data forever.

    Product advantages

    • 2MPx WLAN camera for indoors and outdoors
    • Full HD resolution (1920 x 1080 pixels) at 25 fps and 115° viewing angle for more detail in the picture
    • WDR (120 dB) for more detail even at backlighting and strong contrasts
    • Motion detection via software directly in the camera for low storage requirements and fast finding of the desired recording
    • With H.265 Plus provides 2 times more recording capacity
    • Integrated IR LEDs for best visibility at night/darkness, up to 30 meters
    • Easy mobile access with the ABUS Link Station App - no router settings required
    • Sends pictures via e-mail or FTP
    • PoE (Power over Ethernet)-compatible

    Downloads

    General downloads:

    Declarations of conformity:

    Additional information:

    Software:
    Firmware:

    Installation software:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Network Mini Dome Camera
    Network Mini Dome Camera
    Specifications
    Alarm generation: Email
    Aperture: F2.0
    Article program: Performance
    Automatic aperture control: No
    Base event: Motion detection
    Channel width: 20 MHz
    Colour: White
    Compatible brackets: TVAC31500
    Compatible with: TVVR36xxx / TVVR33xxx / NVRxxxxx
    Compatible with Secvest: Yes
    Compatible with Smartvest: No
    Compatible with wAppLoxx: Yes
    Construction type of device: Dome
    DC power supply: 12 V
    Day/night switching: Auto / Manual / Schedule
    Dimensions: (Ø x H) 111 x 82,4 mm
    Dynamic range (WDR): 120 dB
    Encryption: 64/128-bit WEP / WPA/WPA2 / WPA-PSK/WPA2-PSK / WPS
    Focal length: 2,8 mm
    Frequency range: 2,4 - 2,4835 GHz
    Gross weight: 1.1 kg
    Horizontal viewing angle: 115 °
    Housing material: Metal / Plastic
    IR LEDs: Yes
    IR range (up to): 30 m
    IR swivel filter: Yes
    Image optimization: BLC / WDR
    Image sensor: 1/2.8" CMOS
    Image settings: Brightness / Contrast / Saturation / Sharpness / Mirroring
    Language OSD: DE / UK / FR / NL / DK / IT / PL / ES / SE
    Lens mount: M12
    Loudspeaker: Yes
    Max. Air humidity: 95 %
    Max. Operating temperature: 60 °C
    Max. Resolution @ frame rate: 1920 x 1080 @ 25/30 fps
    Microphone: No
    Min. humidity: 10
    Min. operating temperature: -30 °C
    Minimum illumination (IR): 0 lx
    Minimum illumination (color): 0.028 lx
    Net weight: 0.63 kg
    Network connection: 1x RJ-45 10/100 Mbit/s self-adaptive Ethernet Anschluss
    Network connection WLAN: IEEE802.11b/g/n / 11b @ 11Mbit/s / 11g @ 54Mbit/s / 11n @ 150Mbit/s
    Network protocols: TCP/IP / ICMP / HTTP / HTTPS / FTP / DHCP / DNS / DDNS / RTP / RTSP / RTCP / PPPoE / NTP / UPnP / SMTP / IPv6
    Noise suppression: 3D DNR
    Number of users: 32
    Optical wavelength: 850
    PSTI conformity needed: No
    Pan/tilt range: 0° - 355°
    PoE Standard: 802.3af
    Power consumption: 5.3 W
    Privacy zones: 4
    Product group: Video
    Protection class IK: 10
    Protection class IP: 67
    Radio range: (Depending on installation) 20 - 50 m
    Recording modes: Manual / time schedule / motion detection
    Resolution modes: 1920 x 1080 / 1280 x 960 / 1280 x 720 @ 25/30 fps
    Sensitivity: 11b: -90dBm / 11g: -75dBm / 11n: -74dBm
    Shutter speed: 1/3s - 1/100,000s
    Software: ABUS Link Station (iOS & Android) / IP Installer
    Storage medium: MicroSD (max. 128GB) / NAS
    Supported browsers: Internet Explorer, Edge, Chrome, Firefox, Safari
    Transmission power: 11b: 17 +/- 1,5dBm / 11g: 14 +/- 1,5dBm / 11n: 12,5 +/- 1,5dBm
    User levels: 3
    Video bitrate: 0,032 - 8 Mbit/s
    Video compression: H.265 Plus / H.265 / H.264 Plus / H.264 / MJPEG
    WEEE group: 09
    White balance: Auto white balance (AWB) / incandescent lamp / warm light / natural light / fluorescent lamp
