    Security module
    Security module

    Security module

    Description


    Additionally, electronic locking cylinders or exit buttons can be integrated via the security module.

    For safe and proper operation, this device must be installed and regularly maintained by a professional trained by us. Arrange regular maintenance appointments with your installer to ensure trouble-free operation in the long term with the latest security updates and new functions.

    Product advantages

    • Security module for the ABUS door station
    • Manipulation protection for the door station
    • Interface for electric locks

    Downloads

    General downloads:

    Additional information:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    Alarm output (NO/NC): Door Relay (2A 30VDC / 0.5A 125AC)
    Application purpose: Entrance area
    Connectable devices: 2-wire door station
    Connections: 1 x RS-485
    DC power supply: 12 V
    Depth: 25 mm
    Dimensions: (W x H x D) 115 x 48 x 25 mm
    Height: 48 mm
    Housing material: Metal
    Inputs: 1 x Exit Button, 1 x Lock, 1 x Door Magnetic, 1 x Alarm Out and 1 x Wiegand
    Language Manual: DE, GB
    Language Packaging: DE, GB, FR, NL, DK, IT
    Length: 25 mm
    Max. Air humidity: 90 %
    Max. Operating temperature: 55 °C
    Min. operating temperature: -30 °C
    Mounting type: wall mounting
    Net weight: 0.142 kg
    Product group: Video door intercom system
    WEEE group: 5
    width: 115 mm
