    Wi-Fi Outdoor Camera & App

    Description

    Perfect all-around protection in outdoor areas
    This weatherproof WLAN outdoor camera comes with a compatible app for iOS or Android which even technical laymen can use to quickly and easily install the system. With a resolution of 720p and integrated infrared night vision function, the camera delivers brilliant image quality both day and night.

    Event notification and mobile access via app
    Movements within the detection range of the camera are reliably identified by the passive infrared sensor. Recording on the SD card starts automatically. If desired, you will be informed of incidents by e-mail or push notification and can take a snapshot or view the corresponding video image data using the app. With the app, you have simultaneous access to the image material of up to eight cameras. The efficient H.264 data compression reduces the network load to a minimum and increases the storage volume.

    Note on the product:
    This product can only be set up and operated using the app and is not compatible with online access, PC software or recorders.

    The effective IR range will depend on the installation location. If there are surfaces that absorb light or no objects that reflect IR light in the field of view, the IR range will be reduced and/or the video image will be too dark. Reflective objects in the immediate vicinity of the camera (e.g. roof gutter or wall) may also result in the reflection of IR light, which can disturb the image.

    Product advantages

    • For flexible outdoor use
    • Guided step-by-step installation via app (iOS, Android)
    • App access of up to 8 cameras
    • HD 720p resolution and infrared night vision function for brilliant image quality
    • Professional integrated motion detection (PIR sensor)
    • E-mail notification, snapshot function and push notification via app when motion is detected
    • Sturdy, weatherproof outdoor camera (IP66)
    • Recording to SD card (accessory, max. 32 GB)
    • Low network load thanks to compressed data transfer (H.264 compression)

    Downloads

    General downloads:

    Declarations of conformity:

    Additional information:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    Camera type: Tube
    DC voltage supply: 5 V
    Digital zoom: yes
    Electronic shutter: yes
    Encryption: WPA/WPA2/WPA2-PSK (TKIP, 128 bit AES)
    Focal length: 2,8 mm
    Frame rate: VGA @ 20 fps / VGA @ 25 fps / 720p @ 5 fps / 720p @ 10
    Frequency: 2,4 GHz
    Height: 48 mm
    Housing material: Waterproof metal
    IP protection class: 66
    IR LEDs: 6 IR Power LEDs
    IR range (up to): 5 m
    IR swivel filter: Yes
    Image sensor: MP CMOS
    Length: 134 mm
    Lens: 3.6
    Max. operating temperature: 50 °C
    Microphone: Yes
    Min. operating temperature: -10 °C
    Minimum illumination (colour): 1 lx
    Motion detection: PIR /Software
    Net weight: 0,3 kg
    Network access: Ethernet (10/100 Base-T/Base-TX); Wi-Fi (IEEE 802.11 b/g/n)
    Network camera protocols: TCP/IP, UDP, SMTP, NTP, DHCP, ARP
    Number of IR LEDs: 6
    Number of simultaneous accesses: 3
    PIR range: 3 m
    Power consumption: 500 mA
    Range of night vision function: 5 m
    Recording resolution @ frame rate per camera: 720p @ 5/ 10/ 20 fps (max.) incl. audio
    Resolution modes: HD 1280 x 720 incl. audio
    Technology: IP
    Video compression: H.264
    White balance: yes
    Width: 67 mm
