    HD-SDI Repeater

    Description

    This HD-SDI repeater is used to extend the transmission distance of HD-SDI signals. The transmission distance can be extended by up to 150 meters (depending on the cable quality).

    For safe and proper operation, this device must be installed and regularly maintained by a professional trained by us. Arrange regular maintenance appointments with your installer to ensure trouble-free operation in the long term with the latest security updates and new functions.

    Product advantages

    • Extends the range of HD-SDI signals
    • Max. range increase: 150 m (RG6 cable), 80 m (RG59 cable)
    • Status LED for signal quality

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    Certifications: CE
    DC voltage supply: 6 − 15 V
    Data input: 720p50, 720p60, 1080i50, 1080i60, 1080p24, 1080p25, 1080p30, 1080p50, 1080p60, 2K (2048 x 1080) MB/s
    Dimensions: 63,6 x 70 x 26 mm
    Gross weight: 0,4 kg
    Height: 26 mm
    Input: 1 x HD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 494M/495M)
    Language of instructions: DE, UK, FR, NL, DK, PL
    Length: 70 mm
    Max. humidity: 85 %
    Max. operating temperature: 50 °C
    Min. operating temperature: 0 °C
    Net weight: 0,32 kg
    Output: 1 x HD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 494M/495M)
    Power consumption: 500 mA
    Transmission distance: 150 m
    Width: 63,6 mm
