    Door fitting HLN414 ZS

    HLN414 ZS

    • Security Level 6/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for HLN414 ZS
    Awards & Partners
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
    VdS anerkannt
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

    VdS Label – Security Class 1
    VdS Security Class 1
    VdS Label – Security Class 1

    Awards & Partners

    Technologies

    • According to DIN EN 1906 SK 1 and DIN 18 257 ES 0
    • Integrated pulling protection with cylinder cover plus freely rotating special steel disc
    • Increased leverage resistance: solid cams plus inner screws
    • Proven layered construction: hardened steel bottom plate, plus sturdy cover plate
    • HLN ZS: Spacing: 92 mm, square bolt: 10 mm
    • KLN ZS: Spacing: 72 mm, square bolt: 8 mm

    Operation and use

    • For main entrance doors (HLN) and apartment doors (KLN)
    • Grip plate outside, handle inside
    • HLN: Suitable for door thicknesses of 52 - 67 mm
    • KLN: Suitable for door thicknesses of 37 - 47 mm
    • Mounting material for deviating door thicknesses can be supplied

    Variants

    • Finish: F2 (silver anodized)
    • Alternatively available as a handle/handle set

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    colour: F2: Aluminum Nickel Silver
    Cylinder protrusion: 10 - 18 mm
    Beidseitig Drücker: No
    pulling protection: Yes
    Weight: 1240 g
    Design: Technical drawing
    Technical drawing
    Distance measure: 92 mm
    Interchangeable fitting: Yes
    Door fitting for fire doors: No
    Door type: Entry door
    Security Level Home Security: 6
