    Secvest Wireless Key Switch
    Secvest Wireless Key Switch
    Secvest Radio Key Switch

    Secvest 2WAY Wireless Key Switch

    Product advantages

    • Simple to install and operate
    • Rugged housing
    • Pull protection
    • Sturdy housing
    • Cylinder guard

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    Battery - max. battery life: 2 years(s)
    Battery type: 3.6 V AA Li battery (FU2992) or 12 V DC
    Current consumption: 36 mA
    DC power supply: 3,6/12 V
    Dimensions: (WxHxD) 87x117x47 mm
    Environmental class: II
    Height: 117 mm
    Housing material: Aluminium and plastic
    Length: 47 mm
    Max. Operating temperature: 55 °C
    Max. Receive range (building): 30 m
    Max. Receive range (free field): 100 m
    Max. Transmit range (free field): 100 m
    Max. Transmitting range (building): 30 m
    Min. operating temperature: -10 °C
    Mounting location: Indoors and protected outdoor areas
    Net weight: 0.443 kg
    Product group: Operation
    Protection class IP: 55
    Radio frequency: 868.6625 MHz
    Radio power: 10 mW
    Status display: 1
    Tamper monitoring: 1
    Technology: Electronics
    Voltage monitoring: Yes
    WEEE group: 09
    width: 87 mm
