    Rim lock 7010

    7010

    Safely locked: With this additional lock you secure your doors reliably, but also preserve the possibility of a quick escape, e.g. in case of fire.

    • Security Level 9/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for 7010
    Description
    Solid protection for your front doors.
    Your front door must not only be securely lockable, but must also be able to be opened quickly in the event of an escape. This additional lock fulfils these functions. In combination with ABUS door cylinders and strike plates with wall anchoring, the additional lock represents a reliable security solution for your front doors. It secures the locking side with heavy-duty dowels and a strong oval bolt made of solid steel. It is operated from the outside with a key and from the inside with a turning knob, which ensures that it is possible to exit the premises quickly, e.g. in the event of a fire. The lock withstands a resistance of over one tonne.
    • Made in Germany
    Awards & Partners
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
    VdS anerkannt
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

    Awards & Partners

    Technologies

    • VdS approved with Pfaffenhain cylinder KV356
    • Resistant more than one ton load
    • Strong wall anchoring of the striking plate with heavy duty dowels
    • With two alternative thumbturns on the inside
    • Two backsets can be adjusted: 60 and 72 mm
    • Solid oval bolt made from solid steel, locks with two turns
    • Easy to combine with Armoured Escutcheon Plate PZS4060
    • With external cylinder series EC550, three keys included
    • Boxed version: Lock case and striking plate made from metal
    • Blister version: Lock case and striking plate made from plastic
    • Option to equip with EC660 rim cylinder

    Operation and use

    • For entrance doors to secure the locking side (Tip: protect the hinged side additionally)
    • Operated with a key on the outside, with a thumbturn on the inside
    • Available keyed alike with ABUS padlocks and door cylinders

    Variants

    • Finishes: brown, white, stainless steel look
    • Extended 150 mm catch rod for Pfaffenhain and ECCR cylinders up to 160 mm door thickness available
    • Extended door guard available (extended by 30 mm)

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    type of cylinder: Exterior cylinder
    door guard: No
    Weight: 1304 g
    Design: Technical drawing
    Technical drawing
    colour: white
    alarm function: No
    Security Level Home Security: 9
