Padlock steel 83WPCS/53 EC550 ka.

Extreme 83WPCS/53

Hardened special steel and additional shackle guard make it extremely secure. Drainage channels and a plastic coating make it weather-resistant: The Extreme 83WPCS/53 is robust – and flexible thanks to the interchangeable cylinder.

  • Security Level 8/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for Extreme 83WPCS/53
Description
The WP in the name of the Extreme 83WPCS/53 stands for weather protected, because this lock holds its own against rust even in the most severe weather conditions.
A plastic coating around the entire lock body and drainage channels make the padlock extremely weatherproof. In addition, a protective cap shields the cylinder from moisture and dust. These features make the padlock the ideal choice for outdoor use.
Both the lock body and the shackle, which is additionally equipped with a shackle guard, are made of hardened special steel. The padlock thus offers massive resistance when securing high-value assets.
Keyed alike: one key for several locks
You can adapt the lock to existing bitting systems as the cylinder can be exchanged. Even the shackle can be easily replaced. The Extreme 83WPCS/53 combines robust security, corrosion resistance and flexibility.

Technologies

  • Lock body and shackle made of hardened special steel
  • Hardened special steel shackle with NANO PROTECT™ coating for very high corrosion protection
  • Double bolted locking mechanism increases the security of the lock
  • 2 variants: with automatic locking by simply pressing down the shackle or with key retaining, i.e. locking only with a key (key retaining is set up by inserting the Z-bar)
  • Rekeyable: the cylinder can be exchanged and thus also adapted to existing bittings
  • Extremely weather-resistant: complete plastic coating and cylinder protection cap protect the lock from corrosion; drainage channels transport moisture that has penetrated the lock to the outside
  • Shackle can be exchanged within seconds
  • Precision pin cylinder
  • Closed Shackle (CS): shackle guard makes access using forcing tools such as bolt cutters difficult

Operation and use

  • Protection of items with a higher value and with a high risk of theft
  • Suitable for use on grilles, doors, gates, cabinets, toolboxes, cellar windows, sheds, switchgear, barriers, among other things
  • Extremely flexible: can be adapted to different requirements in a short time – thanks to its interchangeable cylinder and the possibility to quickly change the shackle
  • Can be combined keyed alike with various ABUS door cylinders
  • Ideal for extreme weather conditions (e.g. in sea and harbour areas, for securing on vehicles and boats/ships in outdoor use)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
Locking type: key
Width a: 57 mm
Vertical clearance c: 24 mm
Depth e: 34,5 mm
Weight: 270 g
Security Level Home Security: 8
Design: Technical drawing
Technical drawing
colour: black
Horizontal clearance b: 18,5 mm
Shackle diameter d: 8 mm
Height f: 97 mm
Keyed alike: No
