    Lockable window handle FG210
    Lockable window handle FG210 W Triples B/SB

    FG210

    Full control: Your windows can be reliably protected from children's hands and burglars with this lockable window handle.

    • Security Level 3/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more securitySecurity Level 3/15 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for FG210
    Description
    Whether as a childproof safety catch or break-in protection: This window handle can be used universally.
    Your windows should always be reliably secured. Whether it's to protect your children or ward off criminals. You can bet on this lockable handle. The window handle can be mounted on aluminium, plastic or wooden windows. By means of a push button cylinder and reversible key, it closes securely, even when the window is tilted. The window handle is mounted instead of the conventional handle.
    Application example - FG210

    Technologies

    • Individually adjustable, secured bolt, 28–44 mm long
    • 7 mm square bolt, distance of screws 43 mm
    • Also lockable in tilt position
    • Push button cylinder with reversible key
    • Includes one key, triple version includes three keys

    Operation and use

    • Can be used on standard inward opening windows in place of the window handle
    • Also suitable as a child-proof lock
    • The handle is locked by pushing in the cylinder, open with the key

    Variants

    • Finishes: white, silver

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    door guard: No
    Locking type: key
    alarm function: No
    Weight: 248 g
    Design: Technical drawing
    Technical drawing
    type of cylinder: Pressure cylinder
    colour: white
    Window type: Double casement window, Balcony door / patio door, Basement window, Single casement window
    Security Level Home Security: 3
