    Mortice lock EFS PZ L Z 65 72 24

    EFS PZ

    Robust mortice lock with high-quality silent latch for use in steel doors and fire doors

    • Security Level 7/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for EFS PZ
    Description
    The mortice lock EFS PZ with effective silent latch ensures security and low-noise latching of steel and fire doors.
    This mortice lock provides a high level of security with its zinc-plated steel bolt. It has been tested in accordance with DIN 12209:2004 and is therefore suitable for use in fire doors. The latch, which is made of metal and has a high-quality plastic core, snaps shut quietly when the door is closed. The door can then be locked using a key or knob - depending on which lock cylinder you use. The double turn bolt throw is 11 mm, or 22 mm after turning the key the second time. The MPA tested and monitored lock combines the aspects of security and convenience through the high material quality of all product parts as well as the noise-reducing silent latch. The EFS PZ is available for DIN-left and DIN-right doors. The distance measurement is 72 mm, the backset 65 mm and the width of the zinc-plated steel forend 24 mm.
    • Made in Germany

    Technologies

    • tested according to DIN 12209:2004
    • Silent latch made of metal with high-quality plastic core to reduce noise when closing
    • Latch throw 12mm
    • Steel bolt, zinc-plated
    • Bolt throw 11 / 22 mm (two turns)
    • Zinc-plated sheet steel lock case
    • MPA tested and monitored
    • Lock body 165 x 98mm
    • Steel forend 24 x 235mm, zinc-plated

    Operation and use

    • For steel and fire doors
    • When the door is closed, only the whisper silent is engaged
    • The bolt of the mortice lock only locks the door when the door cylinder is used

    Variants

    • DIN left; DIN right

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    colour: zinc plated
    Distance measure: 72 mm
    Depth lock case: 98 mm
    Width forend: 24 mm
    Lock control: Door cylinder
    Weight: 676 g
    Backset: 65 mm
    Height lock case: 165 mm
    Length forend: 235 mm
    Forend shape: angular
    Opening direction: left
    Security Level Home Security: 7
