Window bar lock FOS550

FOS550

Universal linkage: You can secure your patio doors and double casement windows reliably with this window bar lock.

  • Security Level 10/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for FOS550
Description
Window bar lock, security for patio doors and double casement windows.
Narrowly constructed, quickly mounted: Secure your patio and double doors with this bar lock. The two strong securing points secure at the top and bottom. The lock withstands a pressure of over one tonne at both points. The additional window lock is operated by means of a lockable window handle: If the window is closed, the locking bars are also extended.
  • Made in Germany
Application example - FOS550
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

Test seal Ö-Norm – Vienna, Austria
Ö Norm
Test seal Ö-Norm – Vienna, Austria

Awards & Partners

Technologies

  • VdS and DIN-certified
  • Resists more than one ton static load per securing point
  • Two locking points (top and bottom)
  • The system and the window is locked by the window handle
  • Appropriate bar sets have to be ordered separately
  • Incl. two keys

Operation and use

  • Two-point locking for inward opening windows and patio doors
  • Modular construction system up to 3.10 m, if handle is centred on the frame
  • Also for double windows with or without a rebate, with 7 mm square bolt
  • Dead bolting with quality push-button cylinder
  • Unlocking with the key only necessary after dead bolting
  • Can be supplied keyed alike with a variety of other ABUS products
  • Suitable for all surface materials, such as wood, PVC and aluminium
  • Universal DIN-right and DIN-left mounting

Variants

  • Finishes: B, W
  • Length of bars: 75 cm / 118 cm / 150 cm
  • Accessories: Floor strike plate BSB550, strike plate for double casement windows DSB550 B/W, ground socket BH550
  • Alarmed version also available

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
Locking type: key
alarm function: No
Window type: Balcony door / patio door, Basement window, Single casement window, Double casement window
Security Level Home Security: 10
Design: Technical drawing
Technical drawing
colour: white
door guard: No
Weight: 1470 g
