    Multi-point door lock TSS550 S m. EC550

    TSS550

    New standards: With this door bar lock, you can make the access door of your old flat more secure. The hollow bolt technology with hardened saw protection plugs and a solid metal housing provide reliable protection against burglars.

    • Security Level 10/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for TSS550
    Description
    Flat doors of old buildings can be reliably secured with this door bar lock.
    A flat in an old building is a big dream for many people. But unfortunately, they are often inadequately protected against burglars. Especially because retrofitting security options on the ornate, high doors is usually difficult to implement. If you still want to better protect the access door to your old flat, you can rely on this door bar lock. Locking with this door bar lock is done simultaneously at the top and bottom. Individual adjustments can be made due to the adjustable design of the lock. The hollow bolt technology with hardened saw protection plugs and a solid metal housing provide more security. In the standard version, the lock is suitable for door heights up to 2.75 metres, for higher doors up to 4 metres an extended rod set in 2x2 metres is available.
    • Made in Germany
    Application example - TSS550 Application example - TSS550 Application example - TSS550
    Awards & Partners
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
    VdS anerkannt
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

    Test seal Ö-Norm – Vienna, Austria
    Ö Norm
    Test seal Ö-Norm – Vienna, Austria

    Awards & Partners

    Technologies

    • VdS-approved in conjunction with VdS Class A or better door cylinder
    • Proven cavity catch bolt technology with hardened saw-proof plugs
    • Including sturdy outer rosette with pull-guard and bars
    • Universal DIN R / L usability
    • Individually adjustable bar length
    • 28 mm shoot bolt
    • Solid metal housing
    • DIN tested

    Operation and use

    • To make the lockable sides of front doors more secure (tip: add separate locks to the hinges!)
    • Solution for doors with ornamental battens and/or cassettes in historic buildings
    • Key operation from inside and outside
    • Full-height door lock
    • Standard finish for door heights up to 2.75 m
    • For door leaf thicknesses ranging from 33 to 104 mm
    • In conjunction with fixing set PA1018 also for outward opening doors

    Variants

    • No cylinder; with cylinder, EC550 (30/60)
    • Colours: white, silver, white-silver (housing white, escutcheon plate silver)

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    type of cylinder: Double cylinder
    door guard: No
    Weight: 1 g
    Design: Technical drawing
    Technical drawing
    colour: silver
    alarm function: No
    Security Level Home Security: 10
