Door fitting KLZS714 FS
Door fitting KLZS714 F1
Door fitting KLZS714 F1

KLZS714 FS

Don't let anything burn: Protect your fire doors against break-in attempts with this door fitting made of high-quality and robust materials.

  • Security Level 8/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KLZS714 FS
Description
With this door fitting you secure fire doors against burglars.
A security risk from doors: The door cylinder often protrudes slightly. Burglars can use this weak point to gain unauthorised access. Your fire doors may also have this shortcoming. Therefore, protect them with a reliable door fitting. This door hardware was specially designed for mounting on fire doors with a door thickness of 37 to 47 millimetres. Several steel plates and extra long steel cams provide stability. A steel insert in the shield provides a high level of protection against tearing. The handle plate of the door fitting is equipped with a steel core and can be adjusted to right- and left-opening doors. The product is VdS and DIN certified and MPA monitored.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

Awards & Partners

Technologies

  • Certified according to DIN EN 1906 SK2 and DIN 18 257 ES1, VdS approved, supervised by the MPA NRW (German institute for testing of materials)
  • Steel core in handle
  • Maximum resistance due to the layer construction: several bottom plates for maximum protection
  • High impact resistance: extra long steel cams, complete with tempered special screws (3 x M6)
  • An additional steel inset provides extra strong leverage/tear-off resistance
  • Integrated pulling protection with cylinder cover plus freely rotating special steel disk
  • Grip plate adjustable to DIN left and right doors
  • Spacing: 72 mm, square bolt: 9 mm
  • U-lever shape

Operation and use

  • For fire doors
  • Suitable for rebated and flush doors, left and right opening
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 37 - 47 mm

Variants

  • Finish: F1 (alu anodized)
  • Alternatively available as a handle/handle set

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
colour: F1: Aluminum Nature
Cylinder protrusion: 10-18 mm
Beidseitig Drücker: No
pulling protection: Yes
Weight: 1680 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: Yes
Door type: Fire door
Security Level Home Security: 8
