    Door fitting KLZS714 FS
    Door fitting KLZS714 F1
    Door fitting KLZS714 F1

    KLZS714 FS

    Don't let anything burn: Protect your fire doors against break-in attempts with this door fitting made of high-quality and robust materials.

    • Security Level 8/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for KLZS714 FS
    Description
    With this door fitting you secure fire doors against burglars.
    A security risk from doors: The door cylinder often protrudes slightly. Burglars can use this weak point to gain unauthorised access. Your fire doors may also have this shortcoming. Therefore, protect them with a reliable door fitting. This door hardware was specially designed for mounting on fire doors with a door thickness of 37 to 47 millimetres. Several steel plates and extra long steel cams provide stability. A steel insert in the shield provides a high level of protection against tearing. The handle plate of the door fitting is equipped with a steel core and can be adjusted to right- and left-opening doors. The product is VdS and DIN certified and MPA monitored.
    • Made in Germany
    Awards & Partners
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
    VdS anerkannt
    Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

    Awards & Partners

    Technologies

    • Certified according to DIN EN 1906 SK2 and DIN 18 257 ES1, VdS approved, supervised by the MPA NRW (German institute for testing of materials)
    • Steel core in handle
    • Maximum resistance due to the layer construction: several bottom plates for maximum protection
    • High impact resistance: extra long steel cams, complete with tempered special screws (3 x M6)
    • An additional steel inset provides extra strong leverage/tear-off resistance
    • Integrated pulling protection with cylinder cover plus freely rotating special steel disk
    • Grip plate adjustable to DIN left and right doors
    • Spacing: 72 mm, square bolt: 9 mm
    • U-lever shape

    Operation and use

    • For fire doors
    • Suitable for rebated and flush doors, left and right opening
    • Grip plate outside, handle inside
    • Suitable for door thicknesses of 37 - 47 mm

    Variants

    • Finish: F1 (alu anodized)
    • Alternatively available as a handle/handle set

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    colour: F1: Aluminum Nature
    Cylinder protrusion: 10-18 mm
    Beidseitig Drücker: No
    pulling protection: Yes
    Weight: 1680 g
    Design: Technical drawing
    Technical drawing
    Distance measure: 72 mm
    Interchangeable fitting: Yes
    Door fitting for fire doors: Yes
    Door type: Fire door
    Security Level Home Security: 8
