Door fitting KLS114

KLS114

Universal and reliable: Make your front door more secure with this door fitting. The layered construction of the door hardware as well as the assembly by means of internal screw connection and strong cams make life difficult for burglars.

  • Security Level 5/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KLS114
Description
Flat doors are often inadequately secured. A door fitting can change that.
You always want to be able to exit out of your front door. Whether you are at home or on the road. But often they are not sufficiently secured. Common problem: Lock cylinders protrude somewhat. Burglars can then simply remove them by force and enter your home. Make your flat door more secure with a door fitting. This door hardware is specially designed for universal use on flat doors with door thicknesses from 37 to 47 millimetres. It is composed of a metal lower shield and a lightweight metal upper shield. Internal bolting and strong cams increase breakaway protection.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

VdS Label – Security Class 1
VdS Security Class 1
VdS Label – Security Class 1

Awards & Partners

Technologies

  • According to DIN EN 1906 SK 1 and DIN 18 257 ES 0
  • Increased leverage resistance: solid cams plus inner screws
  • Proven layered construction: hardened steel bottom plate, plus sturdy cover plate
  • Thickness: 15 mm
  • Spacing: 72 mm, square bolt: 8 mm

Operation and use

  • For apartment doors
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 37 - 47 mm
  • Mounting material for deviating door thicknesses can be supplied

Variants

  • Finishes: F1 (alu anodized), F2 (silver anodized), F3 (anodized brass), F4 (anodized bronze), F9 (stainless steel look)
  • Alternatively available as a handle/handle set

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
colour: F1: Aluminum Nature
Cylinder protrusion: 15 mm
Beidseitig Drücker: No
pulling protection: No
Weight: 892 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: No
Door type: Apartment door
Security Level Home Security: 5
