Door fitting KFG

KFG square

Sure thing: With this door fitting for fire doors you secure your fire doors against unauthorised intruders. It is easily mounted and can withstand a tensile load of 2.5 tonnes.

  • Security Level 4/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for KFG square
Description
Poorly secured doors make it easy for burglars. This door fitting changes that.
If your door is unprofessionally secured, burglars will have an easy time. If you want to protect your entrances and exits against unauthorised entry, you need a robust door fitting made of high-quality materials. This product is made of steel and low-wear plastic. Thanks to pre-assembled steel cams, it is quickly mounted and can easily withstand a tensile load of 2.5 tonnes. It is specially designed for fire doors. The steel core inside ensures operation in an emergency. Alternatively, the door fitting is also available as a handle/handle set.
  • Made in Germany
Awards & Partners
Awards & Partners

Technologies

  • According to DIN 18 273, supervised by the MPA (German institute for testing of materials)
  • Steel base plate plus cover made from high quality PVC
  • Steel core in PVC handle
  • Easy to fit with pre-fixed steel cams
  • Spacing: 72 mm, square bolt: 9 mm
  • U-lever shape

Operation and use

  • Door fitting for fire doors
  • Grip plate outside, handle inside
  • Suitable for door thicknesses of 40 - 66 mm

Variants

  • Finish: black
  • Alternatively available as a handle/handle set

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
colour: black
Cylinder protrusion: 9 mm
Beidseitig Drücker: No
pulling protection: No
Weight: 492 g
Design: Technical drawing
Technical drawing
Distance measure: 72 mm
Interchangeable fitting: Yes
Door fitting for fire doors: Yes
Door type: Fire door
Security Level Home Security: 4
