- Certified according to DIN EN 1906 SK 2 and DIN 18 257 ES 1 ZA, VdS approved
- Maximum resistance due to the layer construction: several bottom plates for maximum protection
- High impact resistance: extra long steel cams, complete with tempered special screws (3 x M6)
- An additional steel inset provides extra strong leverage/tear-off resistance
- Integrated pulling protection with cylinder cover plus freely rotating special steel disc
- Grip plate adjustable to DIN left and right doors
- spacing: 72 mm, square bolt: 8 mm
- U-lever shape
KLZS714 round
Feel safe at home: With this door fitting you protect your house entrance and flat doors against burglars. The robust door hardware stands out especially against attempts to pull off the cylinder.
Awards & Partners
VdS anerkannt
Technologies
Operation and use
- For main entrance doors (HLZS) and apartment doors (KLZS)
- Suitable for rebated and flush doors, left and right opening
- Grip plate outside, handle inside
- KLZS: Suitable for door thicknesses of 37 - 47 mm
- Mounting material for deviating door thicknesses can be supplied
Variants
- Finishes: F1 (alu anodized), F2 (silver anodized), stainless steel, brass, white
- Alternatively available as a handle/handle set
Downloads
Recycling
We have summarised for you which disposal information is important in your country.
Specifications
| colour: | F1: Aluminum Nature |
|---|---|
| Cylinder protrusion: | 10-18 mm |
| Beidseitig Drücker: | No |
| pulling protection: | Yes |
| Weight: | 1421 g | Design: |
Technical drawing |
| Distance measure: | 72 mm |
|---|---|
| Interchangeable fitting: | Yes |
| Door fitting for fire doors: | No |
| Door type: | Apartment door |
| Security Level Home Security: | 8 |
