Door fitting KLS114 ZS

HLS214 ZS

For a safe home: With this door fitting, you protect your front door from attempted break-ins by criminals. It is made of multi-layered steel and specially designed against the forced removal of the door cylinder.

  • Security Level 6/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for HLS214 ZS
Description
You can protect your front door from burglars with this door fitting.
Burglars have an easy time with insufficiently secured doors. The crux: Often the door cylinder sticks out a little. Criminals can exploit this to break it off or drill into it in order to gain access. Therefore, secure your front door with a reliable door fitting. Whether for left- or right-closing doors, this door hardware protects your home against intruders with multi-layer steel, extra-long cams and internal bolting. The construction of the door fitting is specially designed to protect the cylinder from being pulled off. It is suitable for front doors with a door thickness of 52 to 67 millimetres.
  • Made in Germany
Awards & Partners
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany
VdS anerkannt
Test seal Gesamtverband der deutschen Versicherungswirtschaft – Cologne, Germany

VdS Label – Security Class 1
VdS Security Class 1
VdS Label – Security Class 1

Awards & Partners

Technologies

  • According to DIN EN 1906 SK 1 and DIN 18 257 ES 0
  • Integrated pulling protection with cylinder cover plus freely rotating special steel disc
  • Increased leverage resistance: solid cams plus inner screws
  • Proven layered construction: hardened steel bottom plate, plus sturdy cover plate
  • HLT: spacing: 92 mm, square bolt: 10 mm
  • KLT: spacing: 72 mm, square bolt: 8 mm
  • Just one version is necessary to cover cylinder protrusions from 10 - 18 mm

Operation and use

  • For main entrance doors
  • Grip plate outside, handle inside
  • HLS: Suitable for door thicknesses of 52 - 67 mm
  • KLS: Suitable for door thicknesses of 37 - 47 mm
  • Mounting material for deviating door thicknesses can be supplied

Variants

  • Finishes: F1 (alu anodized), F2 (silver anodized)
  • KLS: for apartment front doors (72 mm clearance, 8 mm square shaft)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications
colour: F1: Aluminum Nature
Cylinder protrusion: 10-18 mm
Beidseitig Drücker: No
pulling protection: Yes
Weight: 1106 g
Design: Technical drawing
Technical drawing
Distance measure: 92 mm
Interchangeable fitting: Yes
Door fitting for fire doors: No
Door type: Entry door
Security Level Home Security: 6
