SRG72N

Protected against unauthorised intrusion: This door fitting protects the mortice lock of flat entrance doors with a narrow frame profile. Thanks to the variably adjustable cams, it can be used universally.

All variants for SRG72N

Description

SRG72N SECURITY FOR NARROW FRAME DOORS

This door fitting secures your flat entrance door.

Flat entrance doors are always an object of desire for burglars. Since these are often inadequately secured, criminals often have an easy time of it. Door cylinders often protrude somewhat and can therefore be easily removed by force. Protect yourself against this break-in method with a reliable door fitting. This door fitting has been specially developed for flat entrance doors with a narrow frame profile and a door thickness of 57 to 65 millimetres. It has an automatic lever handle reset mechanism in the inside shield and cams that are variably adjustable to most common hole patterns. This makes assembly child's play.

Technologies

Cam spacing variably adjustable to most common hole patterns
Automatic lever handle reset mechanism in the inside shield
Mounting screws concealed by decorative aluminium shield
for cylinder protrusion of 12 mm
Distance measurement: 72 mm, square bolt: 8 mm
Easy mounting

Operation and use

For universal use on narrow frame doors
Suitable for door thicknesses from 57 - 65 mm

Variants

Colours: F1 (alu anodized), white
Available as a handle set and two handles set

Downloads

General downloads:

Data sheet

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Specifications

colour:	F1: Aluminum Nature
Cylinder protrusion:	12 mm
Beidseitig Drücker:	No
Door type:	Doors with tubular frames
Security Level Home Security:	5

Distance measure:	72 mm
Interchangeable fitting:	Yes
pulling protection:	No
Weight:	1132 g
