Combination lock 78

78

To secure valuables with a low risk of theft, we recommend our combination lock 78 with safe locking system - for example lockers in schools and gyms.

  • Security Level 3/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more securitySecurity Level 3/15 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
All variants for 78
Colours for 78
Description
The combination lock 78 has a high-quality safe locking mechanism.
To secure valuables with a low risk of theft, for example lockers in schools and gyms, we recommend our combination lock 78 with safe locking system. The hardened steel shackle can be locked and unlocked with an individual, three-digit number code. The housing is coated in a special electrochemical process to achieve a high level of corrosion protection. In the 78KC version, the integrated master key function of the combination lock ensures that a superior person can operate all locks with one master key by means of a number code.

Technologies

  • Shackle made from hardened steel
  • 78KC: Master key opens more than 2 000 individual combinations (master key function by cylinder on the back of the lock)
  • High protection against manipulation
  • KTL-coating (black) for better corrosion protection
  • With fixed preset coding

Operation and use

  • To secure valuables/goods of lesser value or at a low risk of theft
  • Handy operation without key, e.g. lockers, cupboards, etc. in schools, companies, etc.

Variants

  • Size: 50 mm, 78KC/50 (Key Control)

Downloads

General downloads:

Recycling

We have summarised for you which disposal information is important in your country.

Disposal & labelling of packaging

Application example - Combination lock 721
Application example - Combination lock 721
Specifications
Locking type: number combination
colour: black-silver
Width a: 48 mm
Vertical clearance c: 21,5 mm
Depth e: 33 mm
Weight: 157 g
Security Level Home Security: 3
Design: Technical drawing
Technical drawing
Security card: No
color of facets: silver
Horizontal clearance b: 21 mm
Shackle diameter d: 7 mm
Height f: 75 mm
Keyed alike: Yes
