    Door cylinder A93NP 10/30 KA as per sample/code
    Schematic representation

    A93

    A93 – for people who need a reliable door cylinder with classic standard functions

    • Security Level 6/10 | ABUS GLOBAL PROTECTION STANDARD ® | A higher level means more security
    All variants for A93
    Description
    Perfect for people who are looking for one or more reliable door cylinders that feature classic standard functions.
    The Door Cylinder A93 is available in nearly all lengths up to a total length of 160mm and in half cylinder and knob cylinder variants. The A93 has an emergency function in lengths of 28/34 and above. The hardened components provide substantial protection against drilling. This means that the door cylinder cannot be drilled out and then removed in order to open the door.
    Application example - A93

    Technologies

    • DIN EN 1303 (160B0C6A/C * ) and DIN18252 (M04A/C * 0/FZG) tested; ISO 9001:2015
    • * Class C only in combination with a security plate class ES1-ZA acc. to DIN 18257 or class SK2 with ZA acc. to DIN EN 1906
    • With emergency function: can be locked from both sides, even if the key is in the lock inside (does not apply to half cylinders, as these can only be locked from the outside)
    • Free-turning function (suitable for FZG tested doors)
    • Tested application in RC2 doors (in combination with a suitable door fitting)
    • Anti-drill protection by hardened steel pins
    • 5 pin cylinder
    • 11mm long key neck (perfect for door fittings with pulling protection)
    • Conversion set A93 for conversion to knob cylinder optionally available
    • ABUS Global Protection Standard (GPS) 6
    • with 3 coded keys

    Operation and use

    • Main entrance doors, apartment doors
    • Available keyed alike with ABUS door bars, rim locks and padlocks, e.g. 86TI
    • Double, half and knob cylinders fulfil the requirements as per DIN EN 1303:2015-08 suffix A, Class B and are therefore suitable for the use in fire doors

    Variants

    • Finish: pearl nickel-plated
    • Double, half, knob and rim cylinders
    • individually boxed
    • free-turning function

    Downloads

    General downloads:

    Recycling

    We have summarised for you which disposal information is important in your country.

    Disposal & labelling of packaging

    Specifications
    type of cylinder: Half cylinder
    colour: nickel pearl
    reversable key: No
    Drill protection: Yes
    Security Level Home Security: 6
    Design: Technical drawing
    Technical drawing
    Security card: No
    Weight: 157 g
    emergency feature: No
    fire resistance doors: Yes
